Fein Logo

Fein KBU35 PQW Universal Permanent Magnet Core Drill

The Fein KBU35 PQW Universal Permanent Magnet Core Drill for holes up to 35mm, Twist Drills up to 16mm and Tapping up to M14.

The Fein KBU35 PQW Universal permanent magnet core drill is a small and powerful variable speed universal magnetic core drill with clockwise/anti-clockwise operation and maximum functionality for flexible working on the construction site.

Perfect power-to-weight ratio thanks to compact, weight-optimised design and FEIN 1100 W high-power motor with tacho electronics for high speed stability for reliable and economical working. With clockwise/anti-clockwise operation, electronic speed setting and a 260 mm stroke range, this is a universal tool for core drilling, twist drilling, tapping, countersinking and reaming. Extremely low-wear tool design with swivel-mounted motor cable protection hose for tough use in industry and manual trades. Permanent magnet for very safe working at height. Uses the tool free QuickIN Weldon tool fitting.

Available in 110 and 240v.

Machine supplied with 3 year warranty

3 Year Warranty image

: £2,125.63 inc VAT
£1,461.60 inc VAT


 Voltage  110v / 240v
Power consumption 1100 Watts
Cutter Capacity 35 mm
Cutter Depth 50 mm
Twist Drill Capacity 16 mm
Tapping Capacity M 14
Countersinking Max 31 mm
Reaming Max 16 mm
Speed (Full Load) 130 – 520 rpm
Core bit holder Tool Free Weldon
Total Stroke Range 260 mm
 Permanent Magnetic holding force Nm 9,000
 Magnet Footprint 195 x 70 mm
 Weight according to EPTA 12.5 kg


  • Extra narrow permanent magnet with magnetic bias.
  • Convenient magnetic holding force display
  • Simple operating concept avoids mix-ups and can be clearly seen by the user.
  • Convenient magnetic holding force display.
  • High magnetic holding force.
  • Tilt sensor.
  • Integrated coolant tank.
  • Feed handwheel can be moved from one side to the other.
  • Speed saving “memory function”.
  • Personal safety switch.

Need to know more about our Fein KBU35 PQW Universal Permanent Magnet Core Drill?

Give us a call on +44 121 506 6095 or drop us an email to enquiries@echopkins.com
Alternatively you can request a callback below, fill out the form and we'll be in touch as soon as possible.
