Fein KBU35-2 QW Universal 2-Speed Magnetic Core Drill

The Fein KBU35-2 QW Universal Magnetic 2 speed Core Drill for holes up to 35mm, Twist Drills up to 16mm and Tapping up to M14.

The Fein KBU35-2 QW Universal magnetic core drill is a small and powerful mechanic 2 speed universal magnetic core drill with clockwise/anti-clockwise operation and maximum functionality for flexible working on the construction site. With the twin speed set up this is ideally suited for twist drill use.

Perfect power-to-weight ratio thanks to compact, weight-optimised design and FEIN 1100 W high-power motor with tacho electronics for high speed stability for reliable and economical working. With clockwise/anti-clockwise operation, electronic speed setting and a 260 mm stroke range, this is a universal tool for core drilling, twist drilling, tapping, countersinking and reaming. Extremely low-wear tool design with swivel-mounted motor cable protection hose for tough use in industry and manual trades. Uses the tool free QuickIN Weldon tool fitting.

Available in 110 and 240v.

Machine supplied with 3 year warranty

3 Year Warranty image

: £2,371.09 inc VAT
£1,630.80 inc VAT


 Voltage  110v / 240v
Power consumption 1100 Watts
Cutter Capacity 35 mm
Cutter Depth 50 mm
Twist Drill Capacity 16 mm
Tapping Capacity M 14
Countersinking Max 31 mm
Reaming Max 16 mm
Speed 1 (Full Load) 130 – 520 rpm
Speed 2 (Full Load) 400 – 1600 rpm
Core bit holder Tool Free Weldon
Total Stroke Range 260 mm
Holding force Nm 9,500
 Magnet Footprint 186 x 70 mm
 Weight according to EPTA 11.10 kg


  • Small with mechanical 2-speed gearbox for twist drilling.
  • Convenient magnetic holding force display
  • Simple operating concept avoids mix-ups and can be clearly seen by the user.
  • Convenient magnetic holding force display.
  • High magnetic holding force thanks to 3-coil magnet, just 70mm wide.
  • Tilt sensor.
  • Integrated coolant tank.
  • Feed handwheel can be moved from one side to the other.
  • Speed saving “memory function”.
  • Personal safety switch.
