Fein KBC36 MAGFORCE Compact Mag Drill with Machine Tapping Set

The Fein KBC36 Magforce Drill complete with the Tapping Set M6 to M12.

The Fein KBC36 Compact Mag Drill impresses is extremely small and light variable speed mag drill with a core drilling performance characterised by high precision and quality. Tough enough for holes with diameters of up to 36 mm with an extremely small at of only 169mm high, 290mm long and only 8.5kg this is an extremely powerful small package. Also reversible allowing for tapping up to M14.
Whether drilling at height or from the side, the KBC36 is the drill for you. 10,000Nm holding force with an integrated tilt sensor and magnetic force indicator making sure that you are always in good position to drill. The ratchet lever operates from both sides making it a doddle to use in confined spaces
The KBC36 has a 1200w high performance variable speed brushless motor that allows you to use it efficiently. The KBC36 uses every bit of power when you need it, while reducing the need for ongoing maintenance by reducing the heat generated and working more efficiently.

Complete with the Fein Mag Drill Machinery Drilling and Tapping Set comprising a large number of tapping accessories in an L-BOXX.
The most common tapping drills for through holes in one set. Perfect for the construction of machines and machine tools.
Twist drills and countersink bits: With this set you can have everything you need for core drilling and blind holes readily to hand.
L-BOXX system: Keep things stowed clearly, tidily and safely. Thanks to the tray for small parts, there is room for all accessories and the L-BOXXs can also be joined together and stacked with ease.
Set comprises of the following: All have 3/4″ Weldon fitting for your mag drill.
2 each tapping drills M6, M8, M10 & M12 (DIN 352 / ISO 13), 1 each twist drills 5.0, 6.8, 8.5 & 10.2mm, 4 x HSS 90° countersink bits 16.5mm dia, 1 x cutting paste & 1 L-Boxx 136.

Available in both 110v and 240v models

Machine supplied with 3 year warranty

3 Year Warranty image

: £2,191.09 inc VAT
£1,507.20 inc VAT

 Cutter Capacity  10 – 36 mm
 Cutter Depth  35 mm
 Tapping Capacity  M14
 Power consumption  1200 Watts
 Speed (Full Load)  130 – 610 rpm
 Core bit holder  Weldon
 Stroke  46 mm
 Magnetic holding force  Nm 10,000
 Magnet Footprint  175 x 80 mm
 Size: H x L  169 mm x 290 mm
 Weight according to EPTA  8.5 kg


  • Brushless motor delivers consistent power levels and efficient operation.
  • Perfect for small or awkward spaces.
  • 10,000Nm holding force.
  • Cuts up to 36mm
  • With forward and reverse motor and electronic speed setting.
  • One of the most compact core drilling machines available.
