Stanley TP03 Trash Pump 3″ Outlet

The Stanley TP03 hydraulically driven trash pump is a submersible trash pump which boasts 1800 lpm output flow and will pump liquids with concentrations of solids up to 75mm (3″) diameter.

The TP03 is a very efficient trash pump and can move large volumes of water and other fluids with concentrations of solids up to 25% by volume. The urethane bowl and impeller are abrasion resistant, resilient and impervious to petrochemical solvents. This makes it ideal for pumping slurry, sand and gravel, as well as materials such as suspended fertilizers.

The pump’s efficient design places the impeller above material flow, reducing blockage, jamming and overall pump wear while keeping liquids moving fast enough to pump high volumes of solids at a much higher head than non-submersible pumps. There are wing nuts on the top plate to allow access to clean out the bowl.

The Stanley TP03 trash pump can run dry without damaging motor or impeller reducing the possibility of downtime. No priming necessary, just drop it into the material and it’s ready for work.

Weight27 kg
Brand

Power Type

Capacity

1688 lpm

Fitting

3" Male Camlock

Hydraulic Flow lpm

26-34

Pressure

105-142

Couplings

Yes

Port Size

Features

  • Lightweight and durable urethane bowl and impeller
  • Submersible, no priming required
  • Able to run dry without damage
  • Lifting eye
