Stanley BR45 Underwater Breaker

The Stanley BR45 underwater breaker for light to medium duty breaking of concrete, rock, coral. it is also suitable for light rod driving and tamping.

The BR45 has a T handle design with a large trigger for precise control, a diaphragm accumulator provides additional blow force. The Stanley BR45 underwater hydraulic breaker is capable of handling considerable back pressure (250psi). This feature is particularly useful as long hose lengths are typical in marine environments and can often lead to increased back pressure.

The breakers feathering on/off valve allows the commercial diver to control the output energy of the tool through the full range from 0 to 1,800 blows per minute making start up and initial tool placement easy.

Weight19.5 kg
Brand

Power Type

Capacity

1500 bpm @ 30lpm

Fitting

1" x 4-1/4" Hex

Hydraulic Flow lpm

26-34

Optimum Flow

30

Pressure

105-140

Couplings

Yes

Port Size

Features

  • T-Handle with large on/off trigger for precise control
  • Stainless steel spool and fasteners
  • Diaphragm accumulator provides additional blow energy and reduces recoil
  • Feathering on/off valve allows easy initial tool bit placement
  • Four tie rod design for durability
  • Operates in any position
  • Modular design for ease of service
  • Latch retainer
