Spitznas HD25 Underwater Hammer Drill SDS Plus 224260010
The Spitznas HD25 SDS Plus 2 2426 0010 underwater hammer drill for subsea drilling in concrete, natural stone and masonry.
The Spitznas HD25 SDS Plus 2 2426 0010 underwater hammer drill is a high-performance hydraulic tool for commercial subsea drilling in challenging materials like concrete, natural stone, and masonry. It is ATEX-approved for safety in hazardous environments, both in and out of water.
Key Features & Specifications
The Spitznas HD25 Hammer drill is a robust, professional-grade tool designed for demanding marine construction and repair projects.
- Drilling Capacity: It can drill holes up to 25mm (1 inch) in diameter in concrete with standard SDS Plus bits.
- Versatility: The hammer mechanism can be deactivated, allowing for versatile use in different materials and applications.
- Safety & Compliance: ATEX-approved, making it safe for use in potentially explosive environments (both underwater and dry). It also features a safety clutch system.
- Handling: It features a “D-handle” design and a large multi-position assist handle for improved maneuverability and control during use
- System Type: It operates on an open-center hydraulic system and is available with a built-in pressure control valve (PRV model) for easy integration with most standard hydraulic power units without needing to adjust the power pack’s working pressure
Enquiry: Spitznas HD25 Underwater Hammer Drill SDS Plus 224260010
| Part no. | ATEX Specification | Shank | Max. drilling dia. in concrete | Speed (free) | Power | Noise level LpA | Vibration level | Weight |
|---|---|---|---|---|---|---|---|---|
| mm | rpm | kW | dB(A) | m/s² | kg | |||
| 2 2406 0010 | II2GExhIIBT5Gb | SDS plus | 5.00-28.00 | 500 | 1.2 | 92.0 | 4.5 | 8.2 |
| 2 2426 0010 | II2GExhIIBT5Gb | SDS plus | 5.00-28.00 | 500 | 1.2 | 92.0 | 4.5 | 8.2 |
Features
