Hopkins CD07 Underwater Core Drill

The Hopkins CD07 underwater core drill has a water swivel attachment which allows the fitment of diamond core bits and water feed. With a wide flow range of 11-38 lpm allows the use of cores from 10-125mm in diameter.

The CD07 core drill is not only supplied with the water swivel attachment but also a standard ½” 3 jaw chuck. This means you can fit diamond cores, steel drill bits, wood drills, wood augers etc, making the tool extremely versatile. Ideal for core drilling in concrete and reinforced concrete as well as natural stone. Other features of the CD07 underwater hydraulic core drill are dual position side assist handle, reverse function, dual spool for open centre and closed centre systems.

The CD07 underwater core drill comes complete flat face quick connect couplings.

Weight3.5 kg
Brand

Power Type

Hydraulic Flow lpm

11-38

Pressure

70-140

Couplings

Yes

Port Size

Features

  • Stainless Steel spools and fasteners
  • Forward-Reverse with variable speed
  • Dual position assist handle provides increased control
  • Oversized trigger with guard for operator comfort
  • Cast-in lifting eye
