Stanley HP10 Petrol Powered Hydraulic Power Pack

The Stanley HP10 hydraulic power pack is a reliable petrol powered HPU delivering 20-40 lpm flow.

The HP10 hydraulic power unit is engineered for continuous professional use and is optimized to deliver ideal flows and pressures to a wide range of hydraulic tools. Its powerful 18 HP Briggs & Stratton engine and best-in-class cooling system delivers the power and heat rejection needed to keep tools working uninterrupted all day in all types of climatic conditions.

The Stanley HP10 powered hydraulic power pack features an intuitive throttle selector which makes changing flow rates very easy. Its feature-rich, dependable operation make the HP10 hydraulic power pack the workhorse of many industries.

EC Hopkins have supplied hundreds of these units over the years into a wide range of applications in challenging environments where, flow, working pressure and cooling have been critical. These applications include diamond chainsawing, anchor rod driving using Stanley breakers, powering a variety of underwater tools on long hose lengths, military and Fire and Rescue applications to name but a few.

Weight 150 kg



Hydraulic Flow lpm




Hydraulic Tank Capacity


Fuel Tank Capacity


Dimensions (cm)

89 x 55 x 74


Electric Start with sealed non-spill battery
Type II or Type III hydraulic circuit with superior cooling.
Tool circuit lockout during start-up – safety feature.
Lift & Latch handle with fold-up side handles.
In tank hydraulic filter with dipstick and easy access filter replacement.

Need to know more about our Stanley HP10 Petrol Powered Hydraulic Power Pack?

Give us a call on +44 121 506 6095 or drop us an email to enquiries@echopkins.com
Alternatively you can request a callback below, fill out the form and we'll be in touch as soon as possible.
